IVF/ED60BK1225D ABC 12"X25' High Temperature Black Duct Hose

ABC EnviroDuct* 600D Polyester Black, Black Heavy Duty Wearstrip, 7" Pitch, SS Lined Belt Cuff Entry, Wire Rope Cuff Exit. Storage Straps

IVF/ED60BK1225D Improved Silicone Lined Heater Ducting

New Silicone Lining

• An enhanced feature of the 600D is the introduction of an initial two feet of silicone lining.
• With the introduction of a silicone lining, burn-through is prevented due to temperature spikes from various fuels.
• The silicone lining will also be introduced into the cuff to ensure the contact point with the heater doesn’t cause burn-through.

Enhanced Maneuverability

• Even with the introduction of a silicone lining, ABC’s 600D fabric is lightweight and flexible.

Single Layer Design

• The single-ply, urethane-coated fabric maintains flexibility without losing its strength. The single layer is maintained throughout the remaining feet.

Sewn Construction

• Manufactured utilizing a sewn heavy-duty wear strip to offer additional abrasion resistance.

Product Lifecycle

• The unique features, including its enhanced design, UV stabilization, and mold and mildew inhibitors, result in a superior life cycle.

*Not recommended for aircraft ground support applications

• Weight: 8 oz/yd² (262 g/m²)
• Temperature Range: -20 to 400°F (-29 to 204 °C) Intermittent
• Wire: Hard-Drawn Steel
• Length: 25′ (7.6 m)

• Color: Black

• Standard Pitch: 7″ (178 mm)
• Optional End Finishes: Silicone Lined Belt Cuff, Wire Rope Coupling
• Wear Strip: Heavy-Duty High Profile Military Specs
• Inside Diameter: 12″

IVF/ED60BK1225D Ships Factory Direct (Lead time 2 Weeks)
